Mount Cutting Board Systems

Open Filter

Showing all 4 resultsSorted by popularity

Compact
Classic
Compact
Elite
Artist
Elite
Simplex
Classic
Usage Level Light Light All Purpose All Purpose
Model Number & Capacity 301‑1 = 32" (81 cm) 350‑1 = 32" (81 cm) 450‑1 = 40" (101 cm) 550‑1 = 40" (101 cm)
Squaring Function No Squaring bar Squaring bar Full 32" (81 cm) Squaring Arm
Minimum Border Size 3/4" (19 mm) 3/4" (19 mm) 3/4" (19 mm) 3/4" (19 mm)
Maximum Border Size 4-1/2" (11.4 cm) 4-1/2" (11.4 cm) 5-1/2" (14 cm) 5-1/2" (14 cm)
Hinging Guide Rail No Yes Yes Yes
Base Board Type 1/2" MDF 1/2" MDF 3/4" MDF 3/4" MDF
Parallel Mat Guide Yes Yes Yes Yes
Production Stops No Yes Yes Yes
Bevel Cutter Push Style Push Style Pull Style Pull Style
Straight Cutter Mat Knife Pull Style 701‑1 Pull Style 701‑1 Pull Style 701‑1
Cuts Standard Thickness Mat Board Yes Yes Yes Yes
Cuts 8 Ply No No No No
Straight Cuts Foam Board Up to 3/16" (5 mm) Up to 3/16" (5 mm) Up to 3/16" (5 mm) Up to 3/16" (5 mm)
Cuts Glass No No No No
Cuts Plexi No No No No
Cuts Paper/Photos No No No No
Replacement Blade 270 270 270 270
View View View View

Tools

Materials

Supplies

Mount Cutting System are widely used in the framing world to cut mounts for picture frames. They consist of a straight edge cutter for the outer sides and a bevel shaped cutter for the inner “Aperture” or “window” of the mount. All the systems we sell come with their own individual tricks and bonus features which allows for easier cutting.
